The uniquely wide choice offered by the Schueco ADS HD range of thermally insulated aluminium doors means that whatever the project, there will be a door that fulfills both the aesthetic and performance specification perfectly.
These stylish, superior quality doors can accommodate single, double and triple glazing up to 55 mm thick, giving them excellent thermal efficiency together with real flexibility in use. Typical applications include education, health, leisure and retail buildings as well as offices and high-end residential developments.
The Schueco ADS HD range is available in single and double leaf configurations, inward or outward opening, and rebated frames with depths of 65, 70 or 75 mm. A wide choice of frame, leaf, mid-rail and bottom rail profiles mean that whatever the requirement, there is a Schueco ADS HD door system to suit.
In terms of reliability and durability, a Schueco ADS HD door has been tested up to EN 12400 Class 8 (1 million cycles), while possible security options include ratings from PAS 24 to higher level EN 1627 RC3.
The comprehensive choice of locking systems includes single-point, multi-point, self-locking and electronic locking, all of which are equipped with stainless steel faceplates classed in EN 1670 as having ‘high corrosion resistance’.
Barrel and surface-mounted hinges can support leaf weights up to 200 kg, while the concealed hinge option is an elegant alternative for weights up to 150 kg. The range encompasses maximum leaf widths up to 1400 mm wide and heights up to 3000 mm.
For public and private sector applications, there is an option of either single or double emergency exit doors to EN 179 and EN 1125 operated by panic- or touch-bars, while decorative solid or glazed panels can be fitted to allow a Schueco ADS HD door to look equally at home in a sophisticated residential situation.
For further information on all the products in the Schueco ADS HD door range, please email mkinfobox@schueco.com
