The Grade II Listed Fellowship Inn was a semi derelict pub that has recently been repurposed as a new cultural centre for the local community and beyond. Selectaglaze assisted the refurbishment with its secondary glazing to address the requirement for noise insulation.
The space relaunched in June 2019 as the ‘Fellowship and Star’ and functions as a pub, microbrewery, cinema, theatre and comedy venue, music hub and rehearsal area. The pub is also home to charity ‘Lewisham Music’, which provides after-school instrument tuition and rehearsals for the Borough’s schools on the first floor.
Given the vital repairs and conservation works the site was to undergo, it was necessary to improve the acoustic efficiency of the original crittal single glazed windows which could not be removed due to conservation restrictions.
Architect Thomas Ford and main contractor Ash Constructing contacted Selectaglaze, as an essential element of the works was to ensure a reduction of noise ingress and breakout from the building. High level insulation was required to create an undisturbed optimal movie experience for film goers and to ensure student’s concentration levels during music lessons in Lewisham Music’s upper floors were not compromised by the busy thoroughfare on Randlesdown Road.
Selectaglaze installed a total of 32 units across all four floors of the Inn. The majority of the openings were fitted with Series 15 horizontal sliders, which is a mid-range horizontal sliding system with more robust but still slender framing sections allowing discreet treatments of larger windows. It can support thicker glass when higher levels of noise insulation are needed.
The original curved windows in the cinema were treated sympathetically, utilising Selectaglaze’s Series 15 units, combined with Series 40 curved fixed light units. The Series 40 fixed light lends itself well to shaping and curving, so these were formed to create the top portion of the windows and then transom coupled to the Series 15, which created access to the primary windows for ventilation and maintenance.
Near to an external staircase serving as a fire escape, Series 40 fixed lights offering 30 mins fire integrity were installed to protect the route in the case of an emergency.
